GI Wall Mounted Eye Washer
Wall Mounted Eye Washer is using in rushing to deal with an emergency, quickly cleaning the deleterious material attached to the eyes.
Controlled, low velocity flow completely rinses eyes and face is not injurious to user.
Eye washer unit deliver 11.5 liters of water per minute.
Valve actuator are easy to locate and readily accessible to user.
Hands-free stay open valve activates within one second.
Spray Head Assembly: Two spray heads. Each head has a dust cover, internal flow control, and filter to remove impurities from the water flow.
Valve: 1/2" Stainless steel stay-open ball valve. The valve is activated by a flag handle. The unit remains
in operation until the handle is returned to the closed position.
Eye Wash Bowl: 11-1/2" diameter. Bowl is ABS plastic.
Pipe and Fittings: Schedule 1" and 1/2" galvanized steel. Furnished with yellow polyethylene covers for vertical piping for corrosion resistance.
Supply: 1/2" NPT male inlet.
Waste: 1-1/4"NPT female outlet.
Working Pressure: 0.2-0 .8Mpa flow pressure, 0.9Mpa maximum static pressure.
Quality Assurance: Valve, bowl, and spray head assembly are factory assembled.

EN 15154-1:2006 & EN 15154-2:2006.

Packing: 1 Piece
Country of Origin: China

Portable Eye Washer 16-Gallon
Self-contained 16-gallon gravity flow eyewash unit uses gravity to deliver water through dual spray heads.
The unit delivers over seven gallons (26 liters) of water for fifteen minutes and is ideal for use where a continuous supply of potable water is not available, especially in remote plant areas, low traffic and/or low hazard areas.
Tank: 16-gallon capacity safety yellow polyethylene tank. Tank has handles on top and side to allow for easy handling. A wide fill opening with a threaded cap permits easy inspection, cleaning, and filling.
Operation: Water flow is activated by pulling down the yellow eyewash tray. Integral full flow nozzles deliver a soft spray of water. Swing tray up to a storage position to stop the flow.
Drain: Wastewater is directed into the drain opening in the tank basin. 3 ft long drain hose in basin directs discharge into a floor drain, storage tank, or other receptors.
Mounting: Stainless steel bracket for a mounting unit on the wall. The unit can also be placed on a countertop or other flat surfaces.
Preparation: Top operate the unit, fill the unit with clean potable water, and add bacteriostatic additive. Additive protects against the growth of bacteria, fungus, algae, and acanthamoeba. The unit should be inspected regularly and water in the unit should be changed at least once every six months.
Discharge time: 15 minutes (minimum) at the flow rate of 1.5L/minutes (minimum).
Weight: N.W 7.8 kg, 68kg full
Quality Assurance: The unit is completely assembled, and water tested prior to shipment.





Standards

EN 15154-4:2009



Packing: 1 Piece
Country of Origin: China
