GI Pedestal Eye Washer
Free-standing, pedestal mounted eye/face wash.
Water flow is activated by either a flag handle or a foot treadle.
Controlled, low velocity flow completely rinses eyes and face is not injurious to user.
Eye washer unit deliver 11.5 liters of water per minute.
Hands-free stay open valve activates within one second.
Spray Head Assembly: Two spray heads. Each head has a dust cover, internal flow control, and filter to remove impurities from the water flow.
Valve: 1/2" Stainless steel stay-open ball valve. The valve is activated by a flag handle or foot treadle. The unit remains in operation until the handle is returned to the closed position.
Eye Wash Bowl: 11-1/2" diameter. Bowl is ABS plastic.
Pipe and Fittings: Schedule 1-1/4" and 1/2" galvanized steel. Furnished with yellow polyethylene covers for vertical piping for corrosion resistance.
Supply: 1/2" NPT male inlet
Waste: 1-1/4"NPT female outlet.
Working Pressure: 0.2-0.8Mpa flow pressure, 0.9Mpa maximum static pressure.
Quality Assurance: Valve and spray head assembly is factory assembled.

EN 15154-1:2006 & EN 15154-2:2006.

Wall Mounted Eye Washer is using in rushing to deal with an emergency, quickly cleaning the deleterious material attached to the eyes.

Eye washer unit deliver 11.5 liters of water per minute
Spray Head Assembly: Two spray heads. Each head has a dust cover, internal flow control, and filter to remove impurities from the water flow.
Valve: 1/2" IPS Stainless steel stay-open ball valve. The valve is activated by a flag handle. The unit remains in operation until the handle is returned to the closed position.
Eye Wash Bowl: 11-1/2" diameter. Bowl is stainless steel.
Pipe and Fittings: Schedule 1" and 1/2" stainless steel.
Supply: 1/2" NPT male inlet.
Waste: 1-1/4"NPT female outlet.
Working Pressure: 0.2-0 .8Mpa flow pressure, 0.9Mpa maximum static pressure.
Quality Assurance: Valve, bowl, and spray head assembly are factory assembled.

Packing: 1 Piece
Country of Origin: China
